What type of refrigeration system does this freezer use?

The walk-in freezer uses a remote refrigeration system with thermostatic expansion and liquid line solenoid valves (TXV/TEV).

Does this freezer include special door features?

Yes, the freezer includes a self-closing flush-mounted door with a heating wire and pressure relief vent.

Is this unit suitable for outdoor installation?

Yes, the walk-in freezer is specified for indoor and outdoor commercial kitchen and restaurant applications.

PolarBox Series 5' x 20' Quick Ship Walk-In Freezer With Floor & Remote Refrigeration

Model: PBFWF5X20-RM

$16,089.00

/Each

Shipping Charges Apply

Ships 5 to 7 Days

Delivering to

Select Location

Non-Returnable return policy

Select Door Hinge*

Select Door Width*

Select LED Lights

Select Kick Plate

Select External Ramp

Model: PBFWF5X20-RM

★Why You'll Love It

Remote Refrigeration: The remote refrigeration system is designed for frozen storage applications in commercial kitchen environments.
Polyurethane Insulation: The polyurethane insulation with 4" thickness and R-28 thermal resistance supports frozen food storage.
Pressure Relief Vent: The pressure relief vent is included with the walk-in freezer door assembly.
Heating Wire Feature: The heating wire feature is included for commercial freezer door operation.
Solid Door Design: The solid door includes self-closing and flush-mounted features for restaurant freezer access.
Keyed Door Lock: The keyed lock supports controlled access in commercial food handling and frozen storage areas.
Galvanized Steel Construction: The white galvanized steel construction with 24-gauge panels is suited for walk-in freezer installations.
Included Components: The unit includes a condensing unit, evaporator, and TXV/TEV valve components for refrigeration installation.
Certified Freezer: UL Listed US, NSF Listed, and DOE certifications are included for commercial refrigeration applications.
Warranty Coverage: It includes a 10-year panel warranty, 1-year door parts warranty, 2-year compressor & parts warranty, and 1-year labor warranty on the refrigeration unit by the manufacturer.

The remote refrigeration system is designed for frozen storage applications in commercial kitchen environments.

$16,089.00

/Each

Shipping Charges Apply

Ships 5 to 7 Days

Delivering to

Select Location

Non-Returnable return policy

Select Door Hinge*

Select Door Width*

Select LED Lights

Select Kick Plate

Select External Ramp

Opening a Restaurant?

Kitchen equipment from start to finish — we've got you covered.

(866) 446-7322

Documents

Technical Specification Sheet.pdf

Spot something off?
Help us improve this page.

Key Specification

Country of OriginProudly Made in America

MaterialWhite Galvanized Steel

Selling Unit1/Each

TypeWalk-In Freezer

Warranty10-Year Panel, 1-Year Door Parts, 2-Year Compressor & Parts, 1-Year Labor on Refrigeration Unit

FeaturesSelf-Closing, Flush-Mounted Door, Heating Wire and Pressure Relief Vent

Country of Origin	Proudly Made in America	Material	White Galvanized Steel	Selling Unit	1/Each
Type	Walk-In Freezer	Warranty	10-Year Panel, 1-Year Door Parts, 2-Year Compressor & Parts, 1-Year Labor on Refrigeration Unit	Features	Self-Closing, Flush-Mounted Door, Heating Wire and Pressure Relief Vent
Product Width	59 inch	Product Depth	236 inch	Product Height	91 inch
Hertz	60 hertz	Phase	1 Phase	Voltage	208-230 volt
Compressor Location	Remote	Door Type	Solid	Insulation Thickness	4 inch
Insulation Material	Polyurethane	Hinge Type	Modular Cam-Lock, Tongue & Groove Design	Door Lock	Keyed Lock
Plug Type	Hardwired	Refrigerant Type	R-448A	Usage	Indoor / Outdoor
Certifications	Ul Listed US, NSF Listed, DOE	Nominal Depth	20 ft	Nominal Width	5 foot
Nominal Height	7 foot	Door Height	77 inch	Floor	With Floor
Included	Condensing Unit and Evaporator	Gauge	24 Gauge	Thermal Resistance	R-28
Material Type	CFC & HFC Free	Refrigeration Type	Remote Refrigeration	Valve Type	Thermostatic Expansion, Liquid Line Solenoid Valve (TXV/TEV)
Number of Doors	1 Door	Series	PolarBox Series	Floor Material	Standard Galvanized Steel Floor
Door Width	Choice of 30" or 36"	Door Style	Swing

Product Overview

The PolarBox Series walk-in freezer is designed for commercial kitchen and restaurant frozen storage applications. It features white galvanized steel construction with 24-gauge panels and polyurethane insulation. The unit measures 59" (W) x 236" (D) x 91" (H) with 4" insulation thickness and R-28 thermal resistance for frozen food storage environments.The PolarBox Series walk-in freezer includes a remote refrigeration system with R-448A refrigerant and a remote compressor location. The unit operates on 208/230 V, 1 phase electrical service at 60 Hz with a hardwired connection. A condensing unit and evaporator are included along with thermostatic expansion and liquid line solenoid valves (TXV/TEV).The PolarBox Series walk-in freezer features one solid door with a 77" door height, keyed lock, self-closing function, and flush-mounted design. Additional features include a heating wire and pressure relief vent. The modular cam-lock and tongue & groove hinge system supports panel assembly for commercial foodservice applications.The PolarBox Series walk-in freezer includes a standard galvanized steel floor and is specified for indoor and outdoor use. This 5 ft nominal width and 20 ft nominal depth freezer is proudly made in America and carries UL Listed US, NSF Listed, and DOE certifications. It includes a 10-year panel warranty, 1-year door parts warranty, 2-year compressor & parts warranty, and 1-year labor warranty on the refrigeration unit by the manufacturer.
