What are the dimensions of this walk-in cooler?

The unit measures 276" (L) x 79" (W) x 87" (H) with nominal dimensions of 23 ft depth and 7 ft height.

What refrigeration system does this model use?

It uses a top mounted refrigeration system with R-448A refrigerant, condensing unit, and evaporator.

What warranty coverage is included?

It includes a 10-year panel warranty, 1-year door parts, 2-year compressor and parts, and 1-year labor on refrigeration unit.

PolarBox Series 6' x 23' Quick Ship Walk-In Cooler With Floor & Top Mounted Refrigeration

Model: PBCWF6X23-TM

$16,189.00

/Each

Shipping Charges Apply

Ships 5 to 7 Days

Delivering to

Select Location

Non-Returnable return policy

Select Door Hinge*

Select Door Width*

Select LED Lights

Select Kick Plate

Select External Ramp

Model: PBCWF6X23-TM

★Why You'll Love It

Steel Construction: White galvanized steel at 24 gauge supports durable commercial kitchen cold storage structure.
Extended Storage Length: Overall dimensions 276" (L) x 79" (W) x 87" (H) with nominal 23 ft depth and 7 ft height support bulk storage capacity.
Thermal Insulation Layer: Polyurethane insulation at 4 in thickness with R-28 thermal resistance supports cold retention performance.
Top Mounted System: Top mounted refrigeration design positions cooling components above the enclosure for layout efficiency.
Refrigerant Control System: R-448A refrigerant system supports regulated cooling operation within the refrigeration setup.
Single Door Access: One solid swing door with 77 in height supports controlled access in commercial kitchen storage.
Secure Locking Door: Keyed lock integrated into door supports restricted entry for food storage handling areas.
Certified Standards: UL Listed US, NSF Listed, and DOE certifications align with commercial kitchen compliance requirements.
Electrical Setup: 208/230 V, 1 phase, 60 Hz hardwired configuration supports fixed installation requirements.
Warranty Coverage: 10-year panel, 1-year door parts, 2-year compressor and parts, and 1-year labor on refrigeration unit included.

White galvanized steel at 24 gauge supports durable commercial kitchen cold storage structure.

$16,189.00

/Each

Shipping Charges Apply

Ships 5 to 7 Days

Delivering to

Select Location

Non-Returnable return policy

Select Door Hinge*

Select Door Width*

Select LED Lights

Select Kick Plate

Select External Ramp

Opening a Restaurant?

Kitchen equipment from start to finish — we've got you covered.

(866) 446-7322

Documents

Technical Specification Sheet.pdf

Spot something off?
Help us improve this page.

Key Specification

Country of OriginProudly Made in America

MaterialWhite Galvanized Steel

Selling Unit1/Each

TypeWalk-In Cooler

Warranty10-Year Panel, 1-Year Door Parts, 2-Year Compressor & Parts, 1-Year Labor on Refrigeration Unit

FeaturesSelf-Closing, Flush-Mounted Door

Country of Origin	Proudly Made in America	Material	White Galvanized Steel	Selling Unit	1/Each
Type	Walk-In Cooler	Warranty	10-Year Panel, 1-Year Door Parts, 2-Year Compressor & Parts, 1-Year Labor on Refrigeration Unit	Features	Self-Closing, Flush-Mounted Door
Product Width	79 inch	Product Depth	276 inch	Product Height	87 inch
Door Height	77 inch	Nominal Depth	23 ft	Nominal Width	6 foot
Nominal Height	7 foot	Hertz	60 hertz	Phase	1 Phase
Voltage	208-230 volt	Compressor Location	Top Mounted	Door Style	Swing
Door Type	Solid	Insulation Thickness	4 inch	Insulation Material	Polyurethane
Hinge Type	Modular Cam-Lock, Tongue & Groove Design	Door Lock	Keyed Lock	Floor	With Floor
Plug Type	Hardwired	Refrigerant Type	R-448A	Refrigeration Type	Top Mounted Refrigeration
Usage	Indoor / Outdoor	Certifications	Ul Listed US, NSF Listed, DOE	Gauge	24 Gauge
Thermal Resistance	R-28	Material Type	CFC & HFC Free	Number of Doors	1 Door
Included	Condensing Unit and Evaporator	Series	PolarBox Series	Floor Material	Standard Galvanized Steel Floor
Door Width	Choice of 30" or 36"

Product Overview

The PolarBox Series walk-in cooler is a commercial-grade cold storage unit for indoor and outdoor food service use. Proudly Made in America, it is built with 24-gauge white galvanized steel. It features 4-inch polyurethane insulation with R-28 thermal resistance for stable temperature control. Dimensions are 276" (L) x 79" (W) x 87" (H), with nominal size of 23 ft depth and 7 ft height.The structure is built with a modular cam-lock, tongue & groove hinge system that supports panel alignment during assembly. A single solid swing door with 77 in height is integrated into the design. The door includes a flush-mounted, self-closing mechanism with a keyed lock for controlled access in commercial food storage areas. One-door layout supports direct entry for inventory handling in commercial kitchens.Top mounted refrigeration system places the cooling assembly above the unit. It uses R-448A refrigerant with controlled operation supported by system components. The unit includes a condensing unit and evaporator as part of the refrigeration package. Electrical configuration includes 208/230 V, 1 phase, 60 Hz with hardwired connection for fixed commercial installation.The unit includes a standard galvanized steel floor with with-floor construction for structural stability. Certifications include UL Listed US, NSF Listed, and DOE compliance for commercial kitchen applications. It belongs to the PolarBox Series and is supplied as 1/Each. Warranty coverage includes 10-year panel, 1-year door parts, 2-year compressor and parts, and 1-year labor on refrigeration unit.
